PGE Gauze Electrode

Reference: PGE - Manufacturer: WonATech-ZIVE LAB

The Pt gauze electrode is normally used for a bulk electrolysis experiment which requires large surface area working electrodes in order to increase the rate of electrolysis. It is a cylinder 50 mm high and 40 mm diameter with a 50 mm connecting wire.

Accessory Catalog

Download (1.37MB)
