Reference: RK200-03 A,B - Manufacturer: RIKA
■  Conformed to the WMO standard.
■  Conformed to the IEC61724-1 standard.
■  Suitable for harsh environments.
■  Equipped with a horizontal indicator device.
■  Double transmission glass.
■  Visual desiccant window.
■  Easy installation.

The RK200-03 pyranometer is manufactured using thermopile-based principles;
The sensing elements are made using multi-contact, coil-plated thermopiles.
The surface is coated with a black coating with a high absorption rate.
The hot contacts are on the surface of the sensor, while the cold junction is located inside the body. The temperature difference between the hot and cold junctions generates electromotive force. The thermoelectric effect is proportional to the solar radiation.
Select Model
€970.00
Tax excluded Envío: 3 a 6 semanas


ISO9060:2018: Class A

ISO9060:1990: Secondary Standard

Spectral Range: 280 ~ 3000 nm

Output: 0-20 MV

4-20 mA, RS485

Supply / 12-24 VDC

Range: 0-4000 W/m²

Sensitivity: 7-14 μV/(W/m²)

Nonlinearity: <± 0.2% (100 ~ 1000 W/m²)

Response Time: ≤ 5 s (95%)

Zero Drift (Temperature Drift: 5 kJ/h): <± 2 W/m²

Stability: <± 0.8%/year

Directional Response: ± 10 W/m²

Effect of Temperature: <1% (-10-40℃)

Operating Temperature: -40℃-+80℃

Recalibration Interval: 2 years

Calibration Base: ISO9847

Weight (unpacked): 0.8kg

Dimensions: 154*101.5mm

Transmission Module: 4-20mA: External, RS485: Built-in

Desiccant: Built-in

Mounting Bracket (optional): Horizontal or adjustable bracket

Ingress Protection: IP67

Storage Condition: 10℃-60℃@20%-90%RH 		 ISO9060:2018 - Class B

ISO9060:1990 - Class 1

Spectral Range - 280 ~ 3000 nm

Output - 0-20 MV

4-20 mA, RS485 - Supply / 12-24 VDC

Range - 0-2000 W/m²

Sensitivity - 7-14 μV/(W/m²)

Nonlinearity - ± 1% (100 ~ 1000 W/m²)

Response Time - ≤30 s (95%)

Zero Drift (Temperature Drift: 5 kJ/h) - < ± 4 W/m²

Stability - < ± 1.5%/year

Directional Response - ± 20 W/m²

Temperature Effect - <4% (-10-40℃)

Operating Temperature -40℃-+80℃

Recalibration Interval - 2 years

Calibration Base - ISO9847

Weight (unpacked) - 0.8kg

Dimensions - 154*101.5mm

Transmission Module - 4-20mA: External, RS485: Built-in

Desiccant - Built-in

Mounting Bracket (optional) - Horizontal or adjustable bracket

Ingress Protection - IP67

Storage Conditions - 10℃-60℃@20%-90%RH

■  Solar energy & photovoltaic power generation
■  Agriculture and forestry monitoring
■  Crop growth monitoring
■  Tourism eco
■  Weather stations
