Reference: LPR10M0T - Manufacturer: SENSECA (Delta Ohm)

◆ Fast response Spectrally Flat Class A pyranometer with integrated heater, tilt sensor and diagnostic features.

► The LPR10M0T Pyranometer is a high-performance sensor designed to measure global solar irradiance on a flat surface (W/m²), capturing both direct and diffuse solar radiation with precision.

► Engineered to meet the highest industry standards, this Fast Response Spectrally Flat Class A pyranometer complies with ISO 9060:2018, WMO raccomandations and IEC 61724-1 requirements for Class A PV Systems.

► LPR10 is equipped with temperature, relative humidity, and pressure sensors, to continuously monitor its operating conditions, allowing for predictive maintenance and ensuring long-term reliability.

► The integrated heater prevents dew and frost formation, maintaining high accuracy in any climate. It features an automatic mode, adjusting based on temperature conditions, or can be manually controlled as needed.

► The RS485 Modbus-RTU output galvanically isolated make the sensor flexible and easy to integrate in any exixting system.

► Using the PC application software DATAsense, it is possible to configure the sensor monitor the measurements in real time and save the values detected during the connection in a file.

Environment of Use: Outdoor
Resolution: 0.1 W/m2
IP Classification: IP67
Communications: RS485 Modbus RTU

LPR10M0T PYRAfast MANUAL

Download (1012.19KB)

LPR10M0T PYRAfast DATASHEET

Download (280.66KB)
