> >>>PIR-N Pyrheliometer (1st Class) Direct Solar Radiation sensor (Electrical output in μV)
PIR-N Pyrheliometer (1st Class) Direct Solar Radiation sensor (Electrical output in μV) View larger
Previous Next

PIR-N Pyrheliometer (1st Class) Direct Solar Radiation sensor (Electrical output in μV)

Nesa srl

New

◆ The pyrheliometer (First Class according to ISO 9060 classification) is an instrument for measurement of direct solar irradiance using a thermopile (10μV/W/m2).

◆ Alternative outputs of 0÷2Vdc, 4÷20mA or RS485 ModBus are provided with optional MCS DIN rail module.

2 777,00 €

tax excl.

Add to wishlist

PIR-N Data Sheet Download (363.3k)
  • High precision direct sun energy sensor
  • thermopile measuring system
  • Compact and light design in aluminium
  • According to WMO standards
  • Spectrum of radiation 250-4000 nm
  • Easy to clean up and maintain
  • According to norms

• Sensor for direct solar radiation at high precision

• Measuring system with thermopile

• Body in aluminum sturdy and compact, easy to install

• Conforms to standard WMO

• Measuring range typical: 0÷2000W/m2, 250÷4000nm

• Field of View: 5°

• Typical sensitivity: 10 μV/(W/m2)

• Output signal: 10 μV/(W/m2), 0÷2Vdc, 4÷20mA, RS485/Modbus

• Operating conditions: -40 ÷ +80°C

• Power supply: 10 ÷ 30Vdc
