FCS-B30 H-30 PEM Fuel Cell 30W

Reference: FCS-B30 - Manufacturer: Horizon Educational

30 W PEM fuel cell with integrated fan for STEM projects, competition, and lab use, delivering clean power with plug-and-play simplicity.

€570.00
Tax excluded Envío: 3 a 6 semanas

Quantity Unit discount You Save
3 2% €34.20
5 4% €114.00
10 6% €342.00
15 8% €684.00
20 10% €1,140.00


FCS-B30 H-30 PEM Fuel Cell 30W is a compact, high-performance hydrogen fuel cell designed for hands-on learning, competition, and real-world applications. It delivers up to 30 W of clean, reliable power with plug-and-play simplicity, making it well suited to classrooms, innovation labs, and advanced energy or mobility projects.

An integrated cooling fan improves thermal performance and durability during extended operation. The stack has been used by university teams in competitive STEM environments, reinforcing its value for demanding projects that need a compact, ready-to-use hydrogen power source.

Beyond power generation, the H-30 helps users explore reaction kinetics, thermodynamics, system electrical needs, cooling behavior, and safe hydrogen operation in practical settings.

  • Rated power: 30 W.
  • Number of cells: 14.
  • Required hydrogen pressure: 0.45-0.55 bar.
  • Recommended ambient temperature: 5-30 C.
  • Stack weight including fan and casing: 280 g.
  • System efficiency at full power: 40%.
  • Self-humidifying design.
  • Performance: 8.4 V at 3.6 A.
  • Hydrogen consumption at rated power: 0.42 l/min.
  • Dimensions: 8.0 x 4.7 x 7.5 cm.
  • Included components: 1 x 30 W fuel cell stack, 1 controller, 1 silicon tube 50 cm long, 1 filter, 2 red plastic pins, 1 valve, and 4 M3-4 inlet/outlet gas fittings.
  • Storage tip: compatible with Hydrostik Pro and Hydrofill Pro for hydrogen supply and refilling.
  • Safety: do not connect or disconnect cables while powered, do not disassemble the unit, and always operate in ventilated areas with an accurate hydrogen sensor.

1 x 30W fuel cell stack
1 x controller
1 x silicon tube (OD 4 x ID 2.5mm), 50cm long
1 x filter
2 x red plastic pin
1 x valve
4 x inlet/outlet gas fitting (M3-4)
