DDW Radial Dendrometer for Rugged conditions (Diameter 3-20 cm)

Reference DDW

Manufacturer: Ecomatik

Condition: New

The Radial Dendrometer DDW is the ruggedized version of the DD-L dendrometer type.
In addition to the features of the simple DD-L version, the DDW dendrometer is modified for the use under especially harsh environmental conditions.

Volume discounts

Quantity	Price (tax excl.)	You Save %
1+	400,00 €	0%
5+	392,00 €	2%
10+	384,00 €	4%
15+	376,00 €	6%

More info about this product.

Share on Facebook!
Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

Overview
SPECIFICATIONS
COMPATIBLE LOGGERS
Data sheet
Download

The Sensor measures:	Radial Dendrometer
Output Signal:	mV
Cable Length:	5 meters
Power Supply:	2,5 to 24 Vdc
Sensor for use in:	Outdoor

DDW Download (2.16M)

Waterproof Diameter Dendrometer, type DDW, for use under extremely moist conditions, on the coast, under snow, near soil surface for tree diameters between 3 and 20 cm, measuring range 11 mm, linearity 1%.
Complete with 5 m sensor cable, extendable to up to 100 m.

Standard configuration:
- Complete with 5 m sensor cable, extendable to up to 100 m.
- Cable configuration: bare ended

A soft, weather-resistant rubber coating protects the sensor from the ingress of water and solid particles.

Advantages (in addition to type DD-L)
■ Suitable for diameters of 3-20 cm

■ Suitable for measurements under water, under snow cover and under strong exposure to dust (eg volcanic ash, desert dust, etc.)

■ Suitable under exposure to corrosive seawater spray

■ Specific order of plant size is possible within 3 to 20 cm diameter range

Limits
■ Not suitable for diameter greater than 20 cm

Delivery
■ Complete with 5 m cable

■ Fixing materials and installation tools (spanner)

Options / order information
■ Cable length (specify in meters)

■ If necessary, different frame size

■ Data logger
