8086 Microprocessor Trainer Kit Nvis M86-02

Reference M86-02

Condition: New

Nvis M86-02 is a single board Microprocessor Trainer Kit based on 16 bit 8086 Microprocessor, which is widely used to train engineers to develop software/hardware for any industrial process & control.
This kit consists of a powerful EPROM monitor, RAM, I / O lines, timer / counter, serial, LCD screen and keypad for human machine interface.

More info about this product.

Share on Facebook!
Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

OVERVIEW
SPECIFICATIONS
Data sheet
Download

Category	Microcomputer Control
Function	Microprocessors
Display:	Yes
DC power supply	Onboard DC Power Supply

Nvis M86-02 Data Sheet Download (87.25k)

• 16K Bytes of EPROM with 16K bytes of Battery Backup RAM.
• 72 I/O Lines, Three Channel Timer/Counter, PC Serial Interface using USART, Interrupt Controller.
• 20x2 LCD Display with 101 ASCII Keyboard.
• Power-full Command like Single Stepping, Break Point, Full Clock Execution, Examine Memory/ Register.
• Uploading & Downloading to and from PC in Windows98/XP/NT.
• In-Built Power Supply.

• 8086/8088 CPU operating at 2.5/5MHz
• 8086 Processor can be replaced by 8088 Processor
• On-board sockets provided to facilitate the use of 8087 Co-processor and 8089 I/O Processor
• 16K bytes of RAM using two nos. of 6264 with Battery Backup expandable up to 256KB.
• 16K bytes of powerful monitor EPROM using two nos. of 27512
72 I/O lines through 3 nos. of 8255 brought at 26 Pins FRC Connector to interface with IC-XX Series.
• 16 bit Timer/Counter through 8253 brought out at 20 Pins FRC Connector.
• RS-232C interface using 8251 brought out at 9 Pins D-Type Connector.
• On-board Interrupt controller using 8259 brought out at 20 Pins FRC Connector.
• On-board using ADC 0809 & DAC 0800.
• On-board Real Time Clock using RTC- 6424.
• On-board Temperature sensor using Lm35.
• 8 bit digital switch for 8 digital input and 8 led for 8 digital output.
• 20x2/40x2/20x4 Alphanumeric LCD Display with Backlite
• 101 ASCII Keyboard interface using 89c2051 operating @ 12MHz
• Powerful Commands like Examine/Edit Memory, Examine/Edit Register, Single stepping, Execution, Block Move can be used through ASCII Keyboard.
• On-board Single Line As sembler & Disassembler.
• Facility for Downloading/Uploading files from/to PC.
• All address, data & control lines are available on KXT Bus 50 pin FRC • Connector to interface with SC-XX Series.
• All ICS are mounted on IC Sockets.
• Bare board Tested Glass Epoxy SMOBC PCB is used.
• In-Built Power Supply of +5V/2A, ±12V/250mA
• Attractive ABS Plastic enclosures.
• User's Manual with sample programs.
• Note : Specifications can be altered without notice in
our constant efforts for improvement.
