PX3UXX05 Differential Pressure / Air Velocity Transducer Sensor with LCD

The PX3 transducer can measure either air pressure or velocity with the flip of a switch.  The PX3 is available in three installation configurations: duct, panel or universal.  Duct and panel models have two pressure and velocity range options:  0-1" WC / 0-3,000 ft/min or 0-10" WC / 0-7,000 ft/min with seven field-selectable sub-ranges for pressure and eight for velocity.  All variants are available with and without display.  The PX3 has an IP65/NEMA 4 environmental rating and a 5-year limited warranty.
