SCT-0400 split-core current sensors transform an AC input current up 1 to 75 Amps to a Output 0.333 Volt AC
SCT-0400 split-core current sensors transform an AC input current up 1 to 75 Amps to a Output 0.333 Volt AC

SCT-075H split-core current sensors transform an AC input current up 50 to 200 Amps to a Output 0.333 Volt AC

Reference: SCT-075H - Manufacturer: Magnelab

The opening is 0.75" wide.



Magnelab's SCT-075H Series Current Sensors meets ANSI revenue grade class C57.13 accuracy class 0.6 with unprecedented linearity and superior phase angle up to 200 Amps passing through the center conductor.  The SCT-075H transforms an AC input current up to 200A to an output of 0.333 Volts. Split-core transformer are ideal for installation on existing electrical wiring by snapping around the conductor. Maximum Voltage: 600V (on bare conductor). The following amperages are available: 50A, 100A, and 200A.  The opening is 0.75" wide.

Features
  • Linearity accuracy +/- 0.5%
  • Phase angle +/- 0.25%
  • Rated input up to 200 Amps
  • Accuracy at 10% to 120% of rated current
  • Operates from 30 Hz to 1000 Hz
  • 8 ft. twisted-pair lead
  • Maximum Voltage: 600V (on bare conductor)
  • Output 0.333 Volt AC at rated current
  • UL recognized, CE, and RoHS compliant
  • 10-Year Warranty
