3552-10D LAQUA Conductivity Electrode (Submersible / General Use Type) Conductivity Cell

Horiba

3552-10D LAQUA Conductivity Electrode (Submersible / General Use Type) Conductivity Cell

Horiba

3552-10D LAQUA Conductivity Electrode (Submersible / General Use Type) Conductivity Cell

Reference: 3552-10D (3014081545) - Manufacturer: HORIBA

Conductivity Electrode (with 1m cable, BNC and phono jack)

- For general purpose use
- Glass body, Platinum/Platinum black, k=1, conductivity cell with integrated temperature sensor

Cell Constant (cm^-1)	1
Measurement Range	1µS/cm to 100mS/cm
Sample Volume Required (ml)	15
Temperature Sensor	Integrated
Temperature Range	0 to 100 °C
Connectors	BNC, phono jack
Cable Length	1m
Overall Length	150mm
Diameter	12mm
Cell Material	Platinum coated with platinum black, glass body

The actual cell constants are within ±10% of the nominal value.

- WATER QUALITY -: Conductivity Electrodes
The Sensor measures:: Conductivity

English Brochure

Download (3.07MB)

Download (239.31KB)
