NTC10KSUPM1 Surface Temperature Transducer

Reference NTC10KSUPM1

Manufacturer: Capetti Elettronica s.r.l.

Condition: New

Surface temperature transducer.
The NTC10KSUP is a surface temperature transducer made up by a 30x30x6mm aluminium plate provided with two holes for an easy fix.

May be interfaced with:
All WineCap™ product line dataloggers with NTC10KΩ BETA 3977 transducer input (WSDxx-xx10KB1/SDxx-xx10KB1)
All WineCap™ product line probes withNTC10KΩ BETA 3977 transducer input (WSSxx-xx10KB1).

More info about this product.

Share on Facebook!
Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

OVERVIEW
SPECIFICATIONS
APPLICATIONS
Data sheet
Download

The Sensor measures:	Temperature of a surface
Sensor IP Rating	IP68

NTC10KSUPM1 Data Sheet Download (241.45k)

► 0.1°C accuracy in 0°C÷+60°C range NTC10K
► 30x30x6mm aluminium plate with 2 fixing holes
► Cable lenght: 50cm
► IP68
► Working range between -30°C to 100°C.

Material: Aluminium plate with 2 fixing holes

Cable: Cable lenght: 50cm

Sensible element: NTC10KΩ BETA 3977

Temperature range: -30°C ÷ +100°C

Sealing: IP68

Dimensions: 30x30x6mm

Accuracy: 0.1°C (0°C ÷ 60°C)
