AO-HT-192 3D Laser Range Finder (0,05 ~ 100m)

Reference AO-HT-192

Manufacturer: HTi

Condition: New

The AO-HT-192 laser distance meter (100m measurement range) is a laser distance meter with a measurement range of 0.05-100 meters, distance accuracy of ± 3.0mm, functions that help to work like calculate area , volume.

More info about this product.

Share on Facebook!
Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

OVERVIEW
SPECIFICATIONS
Data sheet

The Sensor measures:	Linear and volumetric distance
---------- INDUSTRY ------------	Laser rangefinder

AO-HT-192 (100m) laser measuring unit, measuring from 0.05 to 100 meters with an accuracy of ± 3.0mm distance that functions as a calculated volumetric measurement. Average, maximum - minimum and continuous measurement.

The HT-192 laser rangefinder has an LCD backlight display, making it visible even in the dark. Dust resistant according to IP54 standards, it works with 2 AAA batteries. Measurement results can be stored in internal memory for values of 20.

1) Measurement range: 0.05 ~ 100M

2) Measurement accuracy: ± （3.0mm + 5 * 10-5 * D）

3) Unit of measure: feet, inches and meters

4) Laser grade: Grade II

6) Laser parameters: 620-670nm, <1mw

7) Power type: battery powered (1.5V battery)

8) Item size: 11.7 * 6 * 3CM

9) Pythagoras: 3 points, partial height

10) Memory: 20 results

11) Main Color: Black

12) Smallest unit shown: 1mm

13) Auto power off: 3 minutes of inactivity
