DVer Vertical Growth Dendrometer (Diameter +8 cm)

Reference DVer

Manufacturer: Ecomatik

Condition: New

The Vertical growth dendrometer is designed to determine vertical changes (not growth) of trees continuously.

Volume discounts

Quantity	Price (tax excl.)	You Save %
1+	373,00 €	0%
5+	365,54 €	2%
10+	358,08 €	4%
15+	350,62 €	6%

More info about this product.

Share on Facebook!
Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

Overview
compatible data loggers
Data sheet
Download
Accessories

The Sensor measures:	Perimetral Dendrometer
Output Signal:	mV
Cable Length:	5 meters
Power Supply:	2,5 to 24 Vdc
Sensor for use in:	Outdoor

DV Download (2.16M)

The DL18 is a battery...

DL18 Data Logger for Dendrometers and Sap Flow Sensors
290,00 €

Add to cart

Tree stems and their respective sections vary in length and curvature, according to water status (short- to mid-term) wind direction and wind speed (short-term to permanent), snow and fruit load (mid-term to permanent), unbalanced growth or loss of crown parts (long-term to permanent). Vertical changes are a valuable information to assess water status and static characteristics, such as mechanical stress-strain relationships and mechanical stability of trees. In order to disentangle the different causes (water status, mechanical stress), parallel measurements with three vertical dendrometers, oriented in three different cardinal directions are necessary.

Advantages

■ Assessment of mechanical stress-strain relationships

■ Suitable for large trees (diameter>8 cm)

■ Robust installation, resistant against wind, snow, falling branches and fruits

Limits

■ Trunk is injured by drilling (the damage can be minimized by tree resin)

Delivery

■ Complete with 5 m cable and 1 m wire cable

Options / Ordering Information

■ Cable extension (please specify in meters)

■ Installation tools (tree resin, hand drill)

■ Data Logger
