Automated Chemistry Analyzer, Discrete, 120 tests for hour random access

Reference FACA-1240

Manufacturer: MRC

Condition: New

MRCLabAutomated Chemistry Analyzer

More info about this product.

Share on Facebook!
Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

Overview
Specifications
Download

Manual FACA-1240 Download (3.12M)

FACA-1240_SPEC Download (234.85k)

FACA-1240_CE Download (133.53k)

FACA-1240 is an analyzer for clinical biochemical tests, which is researched and developed by photoelectricity, automation and computer technologies. The analyzer tests samples by the transmission of specific-turbidity testing method, and calculates sample concentration according to the Lambert-Beer Law.

● Automated Chemistry Analyzer, Discrete, 120 tests for hour random access.
● Reaction positions - 81 cuvettes, 9 cuvettes/strip
● Reaction temp. 37°C, fluctuation ±0.1°C
● 8 wavelengths: 400, 405, 450, 510, 546, 578, 630, 670 nm
● reagent pre-heating, liquid level detction.
● 10 steps washing system - fully automatic.
● labor saving, simple programing and real walk-away operation.
● 24 hours non-stop reagent cooling compartment.
● Reagent open system, closed system on request.
● micro volume for sample and reagent.
● user friendly software based on windows XP.

Model	FACA-1240
Throughput	Constant throughput around 120 tests/hour
Contents of the testing	Clinical chemistry, Immunoturbidimetric
Analytical modes	End-point, Two-point, Kinetic
Programming	Open system with user defined programs & calculation

Sample/Reagent Handling:

Sample/Reagent tray	40 positions for samples and 40 positions for reagents in refrigerated compartment
Refrigerated temp.	4 ~ 15°C
Reagent volume	R1: 180 ~ 450 µL, 1 µL adjustable R2: 30 ~ 250 µL, 1 µL adjustable
Sample volume	3 ~ 45 µL, 0.5 µL adjustable
Sample & Reagent probe	Collision protection,Liquid level detection & Inventory checking
Probe cleaning	Automatic washing both inside & outside, carry over <0.1%

Reaction System:

Reaction positions	81 cuvettes, 9 cuvettes/strip
Cuvette	Optical length 5mm
Reaction volume	180 ~ 500ul
Reaction temp.	37°C, fluctuation ±0.1°C

Measuring and Optic System:

Lamp	Halogen lamp
Absorbtion range	0 ~ 3.500Abs±1%
Wavelengths	8 wavelengths, including 340nm,405nm,450nm,510nm, 546nm,578nm,630nm,670nm
Resolution	0.0001ABS

Working Condition:

Power supply	AC 100/240V 50/60 Hz
Temperature	10 ~ 35°C
Humidity	35 ~ 80%
Water consumption	Max 2.5 L/hour
Dimention(cm)	L800xW600xH650
Gross weight	80KG
