P6191 Temperature Transducer Pt100 -50°C to +50°C / 4 to 20 mA
P6191 Temperature Transducer Pt100 -50°C to +50°C / 4 to 20 mA
P6191 Temperature Transducer Pt100 -50°C to +50°C / 4 to 20 mA
P6191 Temperature Transducer Pt100 -50°C to +50°C / 4 to 20 mA

P6191 Temperature Transducer Pt100 -50°C to +50°C / 4 to 20 mA

Reference: P6191 - Manufacturer: Comet System
€75.00
Tax excluded Envío: 1 a 3 semanas

Quantity Unit discount You Save
5 2% €7.50
10 4% €30.00
15 6% €67.50


Temperature transducer for Pt100 sensors. Outdoor, indoor use.

For external Pt100 temperature probe.

Included in delivery:

  • Traceable calibration certificate
  • Quick start manual
Technical parameters Value
Output 4-20mA
Measured Value Temperature
Construction Type For External Temperature Probe Pt100
Design Industrial
Temperature Measuring Range -50 to +50°C
Relay Output No
Two-State Input No
Lcd Display No
PoE No
Accuracy of temperature output ±0.3°C
Temperature range of 4-20mA output -50 to +50°C
Temperature operating range -30 to +80°C
Current output - two-wire connection 4-20mA
Break of sensor >24mA
Short circuit of sensor <3.5mA
IP protection IP65
Power 9-30Vdc, typically 24V
Dimensions 88.5 x 117 x 39.5 mm (W x H x D)
Weight approximately 125g
Warranty 2 years
