New
Thermohygrometer
Data logger is designed for recording temperature and humidity. Sensors not included.
The values are stored in a non-volatile electronic memory.
Data transfer to personal computer for further analysis is done via USB-C.
This product is no longer in stock
Availability date:
Environment of Use | Indoor/Outdoor |
Resolution | 0.1ºC / 0.1% RH |
With Display | LCD |
IP Classification | IP67 electronics; IP30 sensors |
Communications | Optional GSM IoT |
Memory Capacity | 500,000 readings |
Parameters Measured | Temperature/Relative Humidity |
This model measures temperature, relative humidity and dew point temperature using an outdoor COMET Digi/E series probe. Its response to the temperature or relative humidity jump is significantly faster than by models with internal sensor. This model is often utilized to monitor areas in which only the probe is installed, whereas the main unit is installed elsewhere. When monitoring remote areas, the maximum probe line wire must not exceed 15 m. The Digi/E series probes provide calibrated measurement values. Hence, they may be replaced without having to modify the device setup.
The battery in the device cannot be charged.
Technical data | |
TEMPERATURE SENSOR | |
Measuring range | according to the connected probe Digi/E |
Accuracy | according to the connected probe Digi/E |
Resolution | 0.1 °C |
Response time t90 of temperature measurement (temperature step 20°C, air flow approximately 1m/s) |
8 min |
HUMIDITY SENSOR | |
Measuring range | according to the connected probe Digi/E |
Accuracy | according to the connected probe Digi/E |
Resolution | 0.1% RH |
DEW POINT | |
Measuring range | according to the connected probe Digi/E |
Accuracy | according to the connected probe Digi/E |
Resolution | 0.1 °C |
GENERAL TECHNICAL DATA | |
Operating temperature | -20 to +60 °C |
Channels | 1x connectable temperature+humidity probe |
Memory | 500,000 values in noncyclic logging mode; 350,000 values in cyclic record mode |
Recording interval | adjustable from 1 s to 24 h |
Display and alarm refresh | adjustable 1 s, 10 s, 1 min |
Recording mode | noncyclic - data logging stops after filling the memory<br>cyclic - after filling memory oldest data is overwritten by new |
Real time clock | year, leap year, month, day, hour, minute, second |
Power | Lithium battery 3.6 V, size AA |
Protection class | IP67 |
Dimensions | 61 x 93 x 32 mm |
Weight (including batteries) | approx. 120 g |
Warranty | 3 years |
Included in delivery:
- U3120
- Manual
- Trackable calibration certificate
- 1 x 3.6V lithium battery
- FREE analytical software Vision COMET
THE MP053 USB COMMUNICATION CABLE IS NOT INCLUDED IN THE DELIVERY
