①. Fully automatic. ②. High precision sample giving system. ③. Each module adapts 32 bit ARM processor. ④. Can be connected to urine tangible composition analyzer.
Test items:
Urobilinogen(UBG), Bilirubin(BIL), Ketone body(KET), Occult blood(BLD), Protein(PRO), Nitrite（NIT), Leukocyte(LEU), Glucose(GLU), Specific gravity(SG), Power of hydrogen(PH), Vitamin C(VC), Micro albumin(MAL), Creatinine(CRF), Calcium ion(CAL).
Features:
1. Fully automatic: Sample presentation, sample injection, sample drop, analysis and report output automatically.
2. High precision sample giving system: Ensure the accuracy and reduce pollution.
3. Each module adapts 32 bit ARM processor, and is connected by CAN(Controller Area Network). Fast and accurate.
4. Particular IC card control system: Reduce batch difference.
5. Particular system upgrade function: Convenient TF card upgrade and maintenance function.
6. Can be connected to urine tangible composition analyzer. Comprehensive report of urine dry chemical test results,organic ingredients miscroscopy results & physical and chemical indicators.
|
Model |
AO-UA-240 |
|
Assay Method |
Albedometry |
|
Throughput |
240 tests/hr (15 seconds/test) |
|
Test Tube Racks Volume |
5 test tube racks(50 samples) |
|
Sample Volume |
Not lower than the marked scale line on the test tube rack |
|
Inhalation Sample Volume |
＜1.0ml |
|
Monochromatic Wavelength |
525nm, 610nm, 660nm |
|
Data Storage |
20000 results |
|
Output |
Standard RS-232 serial interface |
|
Language |
English. Other languages on request. |
|
Printer |
Built-in thermal printer |
|
Working Environment |
15~35℃, Optimum Temperature: 20~25℃, Relative Humidity:≤75%. |
|
Power Supply |
AC 220V, 50Hz |
|
Power |
300VA |
|
Fuse Specifications |
250V 2A |
|
Package Size(W*D*H) |
734×524×885mm |
|
Dimensions(W*D*H) |
660×625×581mm |
|
Net Weight |
65kg |
|
Gross Weight |
100kg |
