HA-17600 Analisador de Hematologia Médica

Reference: HA-17600

Manufacturer: MRC

Condition: New

MRC HA-17600: Analisador automático de hematologia médica com desempenho estável.

More info about this product.

Partilhar no Facebook
Retirar este produto da minha lista de favoritos.
Adicionar este produto à minha lista de favoritos.
Print

GENERAL
Especificaciones
Data sheet
Download
Accessories

Instrumento para:	Hospitais, Lab's, Clínicas
Função:	Analisador de hematologia para medicina

HA-17600 Data Sheet Download (277.33k)

HA-17600 Manual Download (1.25M)

60 testes / hora....

BK-6330 Analisador de hematologia automática de 5 partes (60 testes/hora)

Add to cart

● 20 parameters+3 histograms
● Test Parameters:
WBC,LYM,MUD,GRA,LYM,MID%,GRA%,RBC,HGB,,MCHC,MCH,MCV,RDW-CV,RDW-SD,HCT,PLT,MPV,PDW,PCT,P-LCR
HISTOGRAMS: WBC , RBC ,PLT
● with touch screen
● Sample Volume Prediluted: 20µL, Whole Blood: 9.8µL
● 60 samples per hour.
● Up to 50000 sample results (including histograms) can be stored
● Built-in thermal printer, optional external printer
● Multi-language software available on request.
Throughput 60 samples per hour
● Input/Output RS-232, USB, LAN, keyboard and mouse interface
● Dimension(mm) L436×W363×H367
● Weight 18Kg
Up to 50000 sample results (including histograms) can be stored

Model	HA-17600
Parameters	WBC, LYM#, MID#, GRA#, LYM%, MID%, GRA%, RBC, HGB, MCHC, MCH, MCV, RDW-CV, RDW-SD, HCT, PLT, MPV, PDW, PCT, P-LCR and Histograms for WBC, RBC and PLT
Principles	Electrical resistance for counting WBC, RBC and PLT
Performance	Parameter Precision (CV %): WBC (109/L) 2.0(7.0- 15.0) RBC (1012/L) 1.5(3.50-6.00), HGB (g/L) 1.5(110 – 180) MCV (fL) 0.4(80.0 – 110.0), PLT (109/L) 4(100 – 500)
Sample Volume	Prediluted: 20µL, Whole Blood: 9.8µL
Aperture Diameter	WBC 80µm; RBC 50µm
Throughput	60 samples per hour
Display	10.4'' TFT Color LCD with touch screen, Resolution: 800 600
Alarms	Error messages
Carryover	WBC/RBC/HGB<0.5%, PLT<1.0%
Input/Output	RS-232, USB, LAN, keyboard and mouse interface
Printout	Thermal printer, 55mm width paper, various printout formats, external printer optional
Operating Environment	Temperature: 15°C~35°C; Humidity: 10%~90%
Power Requirement	AC 110-220V, 50/60Hz
Dimension(mm)	L436 W363 H367
Weight	18Kg
