PD110 (3200739843)
New
Handheld Meter only (includes electrode attachment, manual & 2 x AAA batteries)
Availability date:
Number of Channels | 2 channels |
With Display | LCD |
Communications | RS232C |
Memory Capacity | 1000 |
The Sensor measures: | Water Flow |
Power Supply: | 2xAAA/Ni-MH/power adaptor |
Sensor for use in: | Water Quality |
- Dual channel, switchable display
- Automatic pH calibration up to 5 points using NIST, USA, or custom pH buffers
- 0.01 pH resolution
- Offset and slope display
- Automatic / manual temperature compensation
- Temperature calibration function
- Measures dissolved oxygen (DO) concentration in mg/L and % saturation units
- 0.01 mg/L or 0.1% DO resolution
- Compensates salinity, temperature, and atmospheric pressure
- Up to 2 DO calibration points
- Auto log data
- Built-in memory can store up to 1000 data
- Auto-shut off (programmable: 1 to 30 minutes)
- Auto-Hold / Auto-Stable measurement
- Caibration alarm (programmable: 1 to 400 days)
- Built-in electrode holder allows 2 electrodes to be attached on both sides of the meter
- Large backlit LCD: 52mm x 64mm
- RS232C output for connecting the meter to compatible printer or computer
- IP67-rated case: waterproof (withstand 30 mins. immersion in 1m depth of water) and dustproof
- Powered by 2 x AAA (LR03) or Ni-MH rechargeable batteries or power adaptor
- Packaged in new molded carrying case
- 2 years meter warranty
Model |
LAQUAact PD110 Dual Channel pH/ORP/DO/Temperature(°C) |
---|---|
pH Range |
-2.00 to 16.00 pH |
Resolution |
0.01 pH |
Accuracy |
± 0.01 pH |
Calibration Points |
Up to 5 |
Buffer Options |
USA / NIST / Custom |
ORP Range |
± 2000 mV |
Resolution |
1 mV |
Accuracy |
± 1mV or 0.2% of reading (Whichever is greater) |
DO Range |
0.00 to 20.00 mg/L / 0.0 to 200.0 % |
Resolution |
0.01 mg/L or 0.1 % |
Accuracy |
± 0.1 mg/L |
Salinity Compensation |
0.0 to 40.0 ppt |
Barometric Pressure Compensation |
Yes |
Temperature Compensation |
Yes |
Calibration Points |
Up to 2 |
DO Probe |
Galvanic with integrated temperature sensor |
Temperature Range |
-30.0 to 130.0 °C |
Resolution |
0.1 °C |
Accuracy |
± 0.4 °C |
Calibration Option |
Yes |
Memory Data |
1000 |
Auto Log Data |
Yes |
Real-time Clock |
Yes |
Date / Time Stamp |
Yes |
Auto-Shut Off |
Yes (Programmable: 1 to 30 minutes) |
Auto-Hold / Auto-Stable |
Yes |
Offset / Slope Display |
Yes (Independent acid and alkaline slopes depending on calibration) |
Calibration Alarm |
Yes (Programmable: 1 to 400 days) |
Electrode Status |
On screen display |
Diagnostic Messages |
Yes |
Display |
Custom Backlit LCD / Dual Channel / Switchable Display |
Inputs |
2 x BNC, 2 x phono, DC sockets |
Output |
RS232C |
IP Rating |
IP67, shock-resistant |
Power Requirements |
2 x AAA (LR03) or Ni-MH rechargeable batteries or power adaptor |
Battery Life |
> 500 hours |
