AO-SCSJ-V63 Water Purifier Medium Type (Automatic RO/DI Water) (63 L/H)

Model

AO-SCSJ-V63

Water Output Type

RO and DI water

Water Output Speed

63 L/H

Purifying Procedure

PF+AC+RO+AC+DI+TF

Water Supply Requirement

Tap water: TDS <200ppm, 5 ~ 45°C, 1.0 ~4.0 Kgf/cm2

(if inlet TDS >200 ppm, extra pretreatment filter is recommended)

Purification System

Pretreatment Unit

20" spun fiber filter x 1+20" granular active carbon filter x 1 +20" active carbon block filter x 1

RO unit

400 GPD RO membrane x 1

Subsequent unit

10'' granular active carbon filter x 1 + 12 L mixed bed resin cartridge x 1 + 0.2 μm terminal filer x 1

DI Water Quality

Resistivity

> 10 MΩ.cm

Conductivity

< 0.1 μs/cm

Heavy metal

< 0.1ppb

Particle (> 0.22 μm)

< 1 cfu/ml

Bacteria

< 1/ml

RO Water Quality

TDS (Total dissolved solid) of RO water (ppm)< TDS of inlet water x 5 %

Consumption

120 W

240 W

Power Supply

AC 110/220 V ± 10 %, 50/60 Hz

Standard Configuration

Main body (include1 set cartridge) +2 built-in 15 liters tank

Optional

TDS meter

External Size (W x D x H)

470 x 650 x 1100 mm

Package Size（W x D x H)

650 x 740 x 1250 mm

Gross Weight

70 kg
