3051 Analizador de Dureza del Agua

El analizador de dureza Waltron 3051 es el único capaz de proporcionar los resultados más precisos y repetibles para el análisis en línea de dureza de bajo nivel en aplicaciones de agua ultrapura. El 3051 utiliza la química colorimétrica única para lograr los resultados más precisos (+/- 5ppb) para el análisis de la dureza total en agua ultrapura. Proteja sus sistemas de agua de la caldera de los depósitos dañinos de calcio y magnesio mediante monitoreo automático continuo. Actualice su proceso manual de toma de muestras con un análisis en línea preciso y fiable.

Range
0–1000 ppb (Other ranges available upon request)

Accuracy
+/– 5 ppb or +/–3% of full scale, whichever is greater

Reproducibility
+/– 5 ppb or +/– 5% of reading, whichever is greater

Analysis Time
7.5 min

Sampling Frequency (Cycle Time)
One reading every 15 mins, adjustable

Required Maintenance
Once a month replenish reagents, Quarterly replace tubing

Reagent Consumption (approximate)
3 reagents, 2L each per month

Sensor Classification
Colormetric with glass flowcell and LED source

Application
Boiler water, and cooling water

Ambient Temperature Range
10-45ºC analyzer (50-113ºF)

Atmospheric Pressure Range
No Limits

Humidity
Up to 90% not condensable

Unit Dimensions
Height=23.6”(60 cm), Width=15”(38 cm), Depth=8.3”(21 cm)

Positioning and installation details
Wall mounting or with bench support, panel mounting (optional)

Weight
17 kg (37.5 lbs.)

Degree of Protection
IP55 (NEMA 4): Wet section, IP65 (NEMA 4x): Electronics

Alarms
2 or 4 configurable alarm relays

Power Supply
110-220Vac, 50-60 Hz 80 VA

Certification (on request):
Meets low voltage and low electromagnetic compatibility directives

SAMPLE DELIVERY OPERATING CONDITIONS

Temperature Range
5-55ºC (41-131ºF)

Inlet Sample
100–500 ml/min, atmospheric, flexible tubing O.D. 1/4"(6 mm)

Outlet Sample
Atmospheric, waste tubing O.D. 3/8"(9 mm)

PH
3-12

Sample Conditioning Requirements
Filtering between 10 and 60 micron, depending on the matrix, needed only to avoid clogging.

Materials in Contact with Sample
Glass, Silicone, Plexiglass, Stainless Steel AISI 316

SIGNAL OUTPUTS

Analog Outputs:
4-20mA (galvanic isolator module available as option) or 0-5V

Serial I/O for Signals:
Serial data output RS232 standard, RS485 available as option

OPERATIONAL CALIBRATION

Single/Multi Point
Multi-Point: zero and mid range

Matrix Corrections
Yes, sample blank correction

Manual/Automatic
Both
