H221SP Transductor Corriente AC Veris ajustable entre 100A y 300A (salida 4-20mA)

Referencia: H221SP

Fabricante: Veris

Condición: Nuevo

Consulta este producto

Compartir en Facebook
Remove this product from my favorite's list.
Add this product to my list of favorites.
Imprimir

General
Especificaciones
Documentación

H221SP Transductor de Corriente AC Veris con rangos de entrada ajustables entre 100A y 300A (salida 4-20mA)

AlphaOmega-Electronics dispone de los mejores Transductores de Corrientey a los mejores precios.

H221SP analog current transducers provide reliable load trending information for large motor loads (up to 300A), with a proportional 4-20mA signal. This model includes a span potentiometer that allows each sensor to be calibrated for maximum resolution.

APPLICATIONS

Load trending of large motors

Monitor larger motors and other loads up to 300A

Split-core design for easy installation and fast retrofits
Eliminates need for external CTs on large conductors
Large openings for heavy conductors
Monitor critical motors (compressor, fuel, etc.)

Loop powered 4-20mA output

Two-wire design reduces wiring cost
Zero and span adjustments for field flexibility
100% solid state...no moving parts to fail
5-year limited warranty

Especificar en el pedido el rango de Amperios: 100, 150, 200, 250 or 300 Amps
Sensor Power 30mA (max)@12-30VDC
Insulation Class 600VAC RMS
Frequency Range 50/60 Hz
Temperature Range -15° to 60°C (5° to 140°F)
Humidity Range 10-90% RH, non-condensing
Accuracy 2% of FS from 10 to 100% of full scale
Response Time 2 sec.
Zero Adjustment 3.5 to 4.5mA
Agency Approvals UL 508 open device listing
