P6181 Transductor de Temperatura Pt100 -100°C a +200°C / 4 a 20 mA
Transductor de temperatura para sensores Pt100.
Para uso en exteriores e interiores.
Para sonda de temperatura externa Pt100.
Transductor de temperatura para sensores Pt100. Uso al aire libre o de interior.
Para sonda de temperatura Pt100 externa.
Incluye:
- Certificado de calibración trazable
- Manual de inicio rápido
| Technical parameters | Value |
|---|---|
| Output | 4-20mA |
| Measured Value | Temperature |
| Construction Type | For External Temperature Probe Pt100 |
| Design | Industrial |
| Temperature Measuring Range | -100 to +200°C |
| Relay Output | No |
| Two-State Input | No |
| Lcd Display | No |
| PoE | No |
| Accuracy of temperature output | ±0.3°C up to +100°C, ±0.4°C over +100°C |
| Temperature range of 4-20mA output | -100 to +200°C |
| Temperature operating range | -30 to +80°C |
| Current output - two-wire connection | 4-20mA |
| Break of sensor | >24mA |
| Short circuit of sensor | <3.5mA |
| IP protection | IP65 |
| Power | 9-30Vdc, typically 24V |
| Dimensions | 88.5 x 117 x 39.5 mm (W x H x D) |
| Weight | approximately 125g |
| Warranty | 2 years |
