P4141 Transductor de Temperatura Pt1000 -100°C a +30°C / 4 a 20 mA

Referencia: P4141

Condición: Nuevo

Transductor de Temperatura Pt1000 -100°C a +30°C / 4 a 20 mA

Descuentos por volumen

Cantidad	Precio (sin IVA)	Descuento %
1+	40,00 €	0%
5+	39,20 €	2%
10+	38,40 €	4%
15+	37,65 €	5.875%

Consulta este producto

Compartir en Facebook
Remove this product from my favorite's list.
Add this product to my list of favorites.
Imprimir

General
Especificaciones
Accesorios Opcionales

Transductor de temperatura para sensores Pt1000. Uso al aire libre o de interior.

Para sonda de temperatura Pt1000 externa.

Incluye:

Certificado de calibración trazable
Manual de inicio rápido

Technical parameters	Value
Output	4-20mA
Measured Value	Temperature
Construction Type	For External Temperature Probe Pt1000
Design	Industrial
Temperature Measuring Range	-100 to +30°C
Relay Output	No
Two-State Input	No
Lcd Display	No
PoE	No
Accuracy of temperature output	±0.3°C
Temperature range of 4-20mA output	-100 to +30°C
Temperature operating range	-30 to +80°C
Current output - two-wire connection	4-20mA
Break of sensor	>24mA
Short circuit of sensor	<3.5mA
IP protection	IP65
Power	9-30Vdc, typically 24V
Dimensions	88.5 x 117 x 39.5 mm (W x H x D)
Weight	approximately 125g
Warranty	2 years

Pt1000TG8/0, temperature probe, cable 1 m code: SN104	Pt1000TG8/0, temperature probe, cable 2 m code: SN105	Pt1000TG8/0, temperature probe, cable 5 m code: SN108
Pt1000TG8/0, temperature probe, cable 10 m code: SN113	Pt1000TG7/0, temperature probe, cable 1 m code: SN164	Pt1000TG7/0, temperature probe, cable 2 m code: SN165
Pt1000TG7/0, temperature probe, cable 5 m code: SN166	Pt1000TG7/0, temperature probe, cable 10 m code: SN167	2301-220/0, temperature probe, cable 1 m code: SN168
2021-150/0, temperature probe, cable 1 m code: SN169	PTS350A-2/0, temperature probe, cable 2 m code: SN170	2034-220/0, temperature probe, cable 1 m code: SN175
2061-200/0, temperature probe, cable 1 m code: SN178	2061-200/0, temperature probe, cable 2 m code: SN179	2061-200/0, temperature probe, cable 5 m code: SN180
2061-200/0, temperature probe, cable 10 m code: SN181	PTS350A-5/0, temperature probe, cable 5 m code: SN182	PTS350A-10/0, temperature probe, cable 10 m code: SN183
Pt1000TGL40/0, temperature probe, cable 1 m code: SN185	Pt1000TGL40/0, temperature probe, cable 2 m code: SN186	Pt1000TGL40/0, temperature probe, cable 5 m code: SN187
Pt1000TGL40/0, temperature probe, cable 10 m code: SN188	Pt1000TR160/0, temperature probe, cable 1 m code: SN199	Pt1000TR160/0, temperature probe, cable 2 m code: SN200
Pt1000TR160/0, temperature probe, cable 5 m code: SN201	Pt1000TR160/0, temperature probe, cable 10 m code: SN202	Pt1000TR160/0, temperature probe, cable 15 m code: SN203
Pt1000TR160/0, temperature probe, cable 20 m code: SN204	PTS380K/0 temperature sensor with a stainless steel connection head and connector code: SN205	2091-200/0, Stick-in probe, cable 1 m code: SN210
2091-200/0, Stick-in probe, cable 2 m code: SN211	2091-200/0, Stick-in probe, cable 5 m code: SN212	2091-200/0, Stick-in probe, cable 10 m code: SN213
2071-030/0, special probe with CINCH connector code: SN214
