CI-33004 CPLD / FPGA Experiment Board

 1. Atmel ATF1504-15 CPLD chip is compatible with Altera MAX 7064, containing 64 microcells over 1000 usable gates, which is able to reprogram about 10k times.

2. Using Altera MAX+PLUS® II for chip development, users can use graphic or text editor (HDL syntax) to design,simulate and implement digital circuit easily.

3. The program is downloaded from PC to CPLD chip via printer port with JTAG technology.

4. Providing some simple I/Os for design efficiency

5. Suitable for new FPGA designers

6. Best solution for the shortage of budget
