LV-200 LabVIEW I/O Interface Lab

LV-200 also provides a comprehensive Experiment Manual which describes the operation of I /O circuits and peripheral devices as well as the programming of control programs (Virtual Instruments) using G programming language.

 1. Data transfer and communication between LV-200 Lab and computer via USB interface
2. Digital output devices : LED BAR and 7-Segment LED display provided for digital data display
3. Digital input devices : Data Switches provided for digital data input
4. A/D and D/A converters applied for input and output applications of analog signal and digital data
5. Providing a number of hardware such as stepping motor, EEPROM and LCD for control application
    of peripheral devices
6. Comprehensive Experiment Manual including a detailed description of software and hardware
7. DC power supplies available for internal and external circuits
8. All experiments can be run on a trial-version LabVIEW software.

01. Digital output control
02. Digital input control
03. Digital I/O control
04. A/D converter control
05. D/A converter control
06. Stepping motor control
07. LCD control
08. EEPROM control
09. Advanced applications:

Counter, stepping motor controller using event structure, LCD advertising display from front panel, LCD advertising display from EEPROM, two-channel oscilloscope, digital voltmeter, acquiring data and storing in EEPROM, two-channel function generator
