Scientech2211 TechBook for Frequency Division Multiplexer/Demultiplexer

Scientech 2211 has the provision for onboard modulating signal as well as voice input. For reducing the complexity same carriers are used for demodulation also. In actual FDM communication method carrier is obtained through the modulated output only. But the basic concept remains the same. DSB-SC modulation technique is used for modulation and demodulation.

Scientech TechBooks are compact and user friendly learning platforms to provide a modern, portable, comprehensive and practical way to learn Technology. Each TechBook is provided with detailed Multimedia learning material which covers basic theory, step by step procedure to conduct the experiment and other useful information.

Product Features:

• Self contained and easy to operate

• Two variable modulating (sinusoidal) input channels with provision of voice inputs

• Two DSBSC modulators for frequency band translation of two test signals

• Two Carrier Generators

• Two sets of audio input amplifier

• One adder/transmission amplifier

• Two Demodulators

• Two low pass filters for smooth output

• Study of Frequency Division Multiplexing / Demultiplexing with sinusoidal & audio inputs

• Study of Fourier Spectrum of FDM

• Study of DSBSC Modulation/Demodulation
