Reference: PY2-C-025 - Manufacturer: Capetti Elettronica s.r.l.

Rectilinear displacement transducer with ball tip.

► The PY2-C-025, linear position transducer, with useful electrical stroke of 25mm, allows the position detection of moving mechanical parts.
► The technology adopted to transduce the position measurement is POTENTIOMETRIC and of military origin, where a resistive track and collector are electrically connected by means of contact brushes mounted on the cursor.

help_outlineAsk for Quote

PY2-C-025 Rectilinear Displacement Transducer with ball tip

I accept privacy policy rules



Rectilinear displacement transducer with ball tip - Provided with five-pin connector - 25mm useful electrical stroke.

Useful electrical stroke (C.E.U.): 25

Resolution: Infinite

Displacement speed:  ≤ 10 m/s

Displacement force:  ≤ 4 N

Life:  >>25x106m strokes,or 100x106 operations, whichever is less (within C.E.U.)

Vibrations:  5...2000Hz, Amax =0.75 mm amax. = 20 g

Shock:  50 g, 11ms.

Tolerance on resistance:  ± 20%

Recommended cursor current:  < 0,1 µA

Maximum cursor current:  10mA

Electrical isolation:  >100MΩ a 500V=, 1bar, 2s

Dielectric strength:  < 100 µA a 500V~, 50Hz, 2s,1bar

Actual Temperature Coefficient of the output voltage:  < 1,5ppm/°C

Working temperature:  -30...+100°C

Storage temperature:  -50...+120°C

Case material:  Anodised aluminium Nylon 66 G 25

Control rod material:  Stainless steel AISI 303

Fixing:  Brackets with variable longitudinal axis



The Sensor measures:
Linear distance
