AO-WDC6E Compact Ultasonic Weather Station

The WDC6E compact mini automatic weather station can simultaneously monitor multiple optional meteorological parameters:
- wind speed
- wind direction
- temperature & humidity
- pressure
- precipitation
- solar radiation, UV radiation, luminance and PM1.0/2.5/10 are optional and can be expanded in "Select Model" or can be found in Advanced model AO-WDC6SE.

Measurement of precipitation adopts advanced small 24GHz Doppler radar. The speed rate of drops is registered with a 24 GHz radar system. By comparison between the speed rate and the size of drops, the quantity of rain or its intensity is registered.
The rain/precipitation type (rain/snow/snow-covered rain/freezing rain/hail) is determined due to the speed rate of the rain.

The adoption of newest technologies and design, make hte structure more compact and robust. There is no need to conduct maintenance or calibrations after the initial installation.
It is very suitable for integrating into Agrometeorological Systems.

Typical Applications:
 -   Weather stations for households
 -   Meteorological observation on farmlands
 -   Wind speed & direction monitoring for tower cranes
 -   Smart city distributed weather stations

► AO-WDC6SE-1: wind speed, wind direction, temperature, humidity, air pressure.
► AO-WDC6SE-2: wind speed, wind direction, temperature, humidity, air pressure, precipitation.
► AO-WDC6SE-3: wind speed, wind direction, temperature, humidity, air pressure, precipitation, solar radiation.
► AO-WDC6SE-4: wind speed, wind direction, temperature, humidity, air pressure, precipitation, solar radiation, UV.
